Ferrari 550 GTS Maranello specification

Chassis
Steel frame, aluminium roof and rear quarters, with all other bodywork panels in carbon fibre composite. Front engine/rear drive layout.

Engine
Prodrive-designed V12, based on original Ferrari block. Dry sump, double overhead cam, 4 valves per cylinder. To comply with regulations 2 x 31.2 mm air restrictors. Fuel tank capacity 100 litres.

Capacity and Power
6 litre – Prodrive increased capacity from original 5500cc to 5853cc
Horsepower - 600+ bhp @ 7000 rpm. Torque - 700+ Nm

Transmission
Xtrac 6-speed sequential gearbox longitudinally mounted at the rear axle.

Clutch
AP carbon 3-plate

Suspension
Double wishbone front and rear. Adjustable front anti-roll bar and adjustable dampers front and rear.

Brakes
Front and rear, with 6-pot callipers and 15” (375mm) vented carbon discs, brake balance adjustable by driver.

Wheels and Tyres
Prodrive-designed, OZ forged magnesium. Front 18” x 12”, rear 18” x 14”. Michelin or Pirelli tyres (dependant upon team/series).

Dimensions
Length: 4610 mm
Width: 1995 mm
Wheelbase: 2500 mm
Weight: 1100kg
